| Print Method |
Thermal inkjet |
| Print Resolution |
600 dpi × 1200 dpi native; up to 1200 dpi × 4800 dpi |
| Droplet Size |
4 picolitre |
| Print Speeds |
Up to 114 mm (4.5") per second |
| Inks |
Separate high capacity ink tanks for cyan, magenta and yellow (CMY), process black (dye or pigment ink) |
| Printhead |
User replaceable, multi-use printhead |
| Colours |
16.7 million |
| Colour Matching |
ICC colour profiles included; ability to add custom ICC colour profiles for other media types |
| Print Width |
13 mm - 210 mm (0.5" - 8.25") |
| Media Width |
38 mm - 212 mm (1.5" - 8.375") |
| Print Length |
13 mm - 1524 mm (0.5" - 60") |
| Media Types |
Roll-fed pressure-sensitive labels, roll-fed tags, fan-fold labels or tags |
| Media Sensing |
Moveable see-through sensor for die-cut labels; reflective sensor for labels and tags with black stripe; can use continuous and pre-printed labels and tags |
| Media Feed |
Internal or external |
| Supply Roll |
152 mm (6") maximum outer diameter on 76 mm (3") core |
| Cutter |
Built-in "pizza-wheel" style label cutter |
| Ink Level Warning |
Calculates actual number of prints remaining based upon ink usage of graphics being printed. |
| Indicator Lights |
Power, Ink, Pause |
| Controls |
Pause, Load/Feed, Unload |
| Operating Systems |
Windows® 8 - 11
Mac OS X 11 - macOS 15 (Sequoia) |
| Data Interface/Connections |
USB 2.0
Wired Ethernet (only for Windows) |
| Label Design Software |
BarTender UltraLite DTM Edition and NiceLabel Free DTM Edition (Windows)
Belight Swift Publisher 5 (Mac)
Can also be used with most other popular label design & graphics programs. |
| Power Requirements |
100 V - 240 V AC (50/60 Hz), 12 V DC, 5.0 A |
| Power Consumption |
Maximum: 60 W |
| Certifications |
UL, UL-C, CE, FCC Class A, RoHS |
| Weight |
16.6 kg |
| Dimensions (W × H × D) |
438 mm × 231 mm × 438 mm |
| Operating Temperature |
10 °C - 35 °C |
| Operating Humidity |
10 % - 60 % RH (non-condensing) |
| Available Versions |
LX4000e with dye-based ink (074435)
LX4000e with pigment ink (074436) |
| What’s in the Box |
LX4000e Color Label Printer, a set of CMY ink tanks, a pre-primed printhead, one 6" × 4" DTM Paper Semi Gloss (dye) or DTM Paper Matte (pigment) starter roll, USB 2.0 cable, EU power cord and instructions.
Label design software and printer driver can be downloaded from the DTM Print website. |
| Recommended Accessories |
DTM Print Label Re-/Unwinders |
| Warranty |
36 months (after product registration, for devices purchased in EU/EFTA countries and UK) |
| Manufacturer |
Primera Technology, Inc. |
