Print Method: HDP® Dye-Sublimation / Resin Thermal Transfer
Resolution: 600 dpi (23.6 dots/mm)
Colors: Up to 16.7 million / 256 shades per pixel
Print Ribbon Options:
• Full-color with resin black, YMCK*, 750 prints
• Full-color with two resin black panels, YMCKK*, 600 prints
Additional ribbon options coming soon. Please contact your HID Global Sales Representative or local HID Integrator for
more information.
HDP Film Options: Clear, 1500 prints
Overlaminate Options: COMING SOON - Overlaminate options will be made available with the upcoming release of the HDP6600 lamination
module. Please contact your HID Global Sales Representative or local HID Integrator for additional information.
Print Speed:**
Batch Mode:
• Up to 230 cards per hour / 16 seconds per card (YMCK* with transfer)
• Up to 126 cards per hour / 29 seconds per card (YMCKK* with transfer)
Accepted Standard Card Sizes: CR-80 (3.375”L x 2.125”W / 85.6mmL x 54mmW)
Print Area: Over-the-edge on CR-80 cards
Accepted Card Thickness: .030” (30 mil) to .040” (40 mil) / .762mm to 1.01mm
Accepted Card Types: ABS, PVC, PET, PETG, proximity, smart and mag stripe cards, optical memory cards, polycarbonate.
Input Card Cartridge Capacity: 100 cards (.030” / .762mm)
Output Hopper Card Capacity: 200 cards (.030” / .762mm)
Card Cleaning: Replaceable cleaning roller (included with each print ribbon)
Memory: 1 GB RAM
Display: User-friendly, SmartScreen™ Graphical OLED Control Panel
Software Drivers: Windows® 10 / 8.1 / 8 / 7 / Server 2016 / Server 2012 / Server 2012 R2 / Server 2008 / Server 2008 R2
Encoding Options:
Supported smart card and magnetic stripe technologies: 125kHz (HID Prox) reader; 13.56 MHz (iCLASS® Standard/SE/
SR/Seos, MIFARE Classic®, MIFARE Plus®, MIFARE DESFire® EV1, ISO 14443 A/B, ISO 15693) read/write encoder; contact
smart card encoder reads from and writes to all ISO7816 1/2/3/4 memory and microprocessor smart cards (T=0, T=1) as
well as synchronous cards; ISO magnetic stripe encoding, dual high- and low-coercivity, tracks 1, 2 and 3.
Supported Access Control Credential Programming
iCLASS® Standard/SE/SR/Seos, MIFARE Classic®, MIFARE DESFire® EV1, HID Prox (Also see the FARGO HDP6600 Card
Encoding Modules Datasheet for additional information)
Interface: USB 2.0 and Ethernet (100 Mbps) with internal print server
Operating Temperature: 65° to 90° F / 18° to 32° C
Humidity: 20 - 80% non-condensing
Dimensions: HDP6600: 13.0”H x 14.5”W x 12.0”D / 330mmH x 368mmW x 305mmD
Weight: HDP6600: 21.0 lbs. / 9.5 kg
Certifications***: UL, CE, FCC, BSMI, MIC, EAC, RCM, CCC, KCC, S-Mark
Supply Voltage: 100-240 VAC, 2.5A max
Supply Frequency: 50 Hz / 60 Hz
Environmental/Energy
Saving Feature GreenCircle® Certified card printer (base models only without encoders)
Warranty:
• Printer – Three years including one year of free printer loaner support (U.S. only); optional Extended Warranty
Program (U.S. only)
• Printhead – Lifetime; unlimited pass
FARGO Secure Materials:
FARGO Card Printer/Encoders require highly specialized media to function properly. To maximize printed card quality
and durability, printhead life and printer/encoder reliability, use only HID Secure Materials.
HID warranties are void, where not prohibited by law, when non-HID Secure Materials are used.
Options:
Dual-sided printing, Card flattener, Magnetic stripe encoder, Contact Smart Card encoder, Contactless Smart Card
encoding modules, 200-card input hopper, Printer cleaning kit. Coming Soon: LMX card lamination module (One
Material and Two Material configurations available), Dual input card hopper module, Physical locks for card hoppers and
consumables access, Secure proprietary consumables system, Custom secure holographic overlaminate.
Software: FARGO diagnostic utility with Color Assist spot-color matching included with printer driver
* Indicates the ribbon type and the number of ribbon panels printed where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black, I=Inhibit, F=Fluorescing, H=Heat Seal
** Print speed indicates an approximate print speed and is measured from the time a card drops into the output hopper to the time the next card drops into the output
hopper. Print speeds do not include encoding time or the time needed for the PC to process the image. Process time is dependent on the size of the file, the printhead
resolution, the CPU, amount of RAM and the amount of available resources at the time of the print.
***Please contact your HID Global Sales Representative or local HID Integrator for additional certification information
