Print Method: Dye-Sublimation / Resin Thermal Transfer
Resolution: 300 dpi (11.8 dots/mm) continuous tone
Colors: Up to 16.7 million / 256 shades per pixel
Print Ribbon Options:
Full-color with resin black and overlay panel, YMCKO*, 250 prints
Full-color half-panel with resin black and overlay panel, YMCKO*, 350 prints
Full-color with two resin black panels and overlay panel, YMCKOK*, 200 prints
Resin black and overlay panel, KO*, 500 prints
Dye-sublimation black and overlay panel, BO*, 500 prints
Resin black (standard and premium), 1000 prints
Resin green, blue, red, white, silver and gold, 1000 prints
Rewrite technology - No ribbon is required
Print Speed**: 7 seconds per card (K*); 12 seconds per card (KO*); 24 seconds per card (YMCKO*); 31 seconds per card (YMCKOK*)
Accepted Standard
Card Sizes: CR-80 (3.375˝L x 2.125˝W / 85.6mmL x 54mmW); CR-79 Adhesive Back (3.313˝L x 2.063˝W / 84.1 mm L x 52.4 mm W)
Print Area:´CR-80 edge-to-edge (3.36˝L x 2.11˝W / 85.3 mm L x 53.7 mm W); CR-79 (3.3˝L x 2.04˝W / 83.8 mm L x 51.8 mm W)
Accepted Card Thickness
.009˝ - .040˝ / 9 mil - 40 mil / .229mm - 1.016mm
Accepted Card Types: PVC or polyester cards with polished PVC finish; monochrome resin required for100% polyester cards;
optical memory cards with PVC finish; rewrite
Input Hopper Card Capacity: 100 cards (.030˝ / .762 mm)
Output Hopper Card Capacity: Up to 30 cards (.030˝ / .762 mm)
Card Cleaning: Card cleaning roller integrated into ribbon cartridge; cleaning roller is automatically replaced with each ribbon change
Memory:32 MB RAM
Software Drivers: Windows® XP / Vista™ (32 bit & 64 bit) / Server 2003 & 2008/ Windows® 7 / MAC OS X 10.5/10.6 / Linux***
Interface: USB 2.0, optional Ethernet with internal print server
Operating Temperature: 65° to 80° F / 18° to 27° C
Humidity: 20–80% non-condensing
Dimensions: Single-Sided Prin:ter: 8.8˝H x 13.7˝W x 7.9˝D / 224 mm H x 348 mm W x 201 mm D
Weight:
Single-Sided: 7.5 lbs / 3.4 Kg; Dual-Sided: 10 lbs / 4.54 Kg
Agency Listings
Safety: UL 60950-1, :CSA C22.2 (60950-1), and CE; EMC: FCC Class A, CE (EN 55022 Class A, EN 55024),
CCC, BSMI, KC
Supply Voltage:100-240Vac, 50-60Hz, 1.6 Amps max.
Supply Frequency: 50 Hz / 60 Hz
Warranty:
Printer – one year; Printhead – one year, unlimited pass with UltraCard™
Options: Single Wire Ethernet and USB 2.0 interface for inline printing and encoding (note: single wire Ethernet encoding is only available for iCLASS® and contact smart card encoding); Dual-Sided Printing Module; Smart Card Encoding Modules(contact/contactless); Magnetic Stripe Encoding Module; Printer Cleaning Kit; Ethernet with Internal Print Server; Secure Proprietary Consumables System
Software: Swift ID™ Embedded Badging Application, FARGO Workbench Diagnosis Utility
Display: Color changing status buttons
* Indicates the ribbon type and the number of ribbon panels printed where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black, O=Overlay, B=Dye Sublimation Black.
** Print speed indicates an approximate print speed and is measured from the time a card drops into the output hopper to the time the next card drops into the output hopper. Print speeds do not include encoding time or the time needed for the PC to process the image. Process time is dependent on the size of the file, the CPU, amount of RAM and the amount of available resources at the time of the print.
***Linux versions: Ubuntu 8.04/9.04, Red Hat 5, Fedora 7/8/9/10/11, Open Suse 10.3, Debian 5.03/5.04, Mandiva one 2009
